Product Details

Designed for coding in the Dairy & Edible Industry. The 9042 is designed specifically to meet the needs of the dairy industry with all of the benefits of the 9040. Are you … > Looking for more efficiency in your manufacturing processes? > Driving your production lines faster and faster? > Searching for more robust equipment for demanding environments? > Wishing for easier and cleaner consumables handling?

• Single or dual printhead systems • G head (printing resolution: 71 dpi) • Up to 4 lines of text per printhead • Print speed: up to 5.5 m/s • Font sizes from 5 dots to two 24-dot lines • Character height from 1.8 mm to 8.7 mm • One and two-dimensional barcodes (Datamatrix) • Wide selection of characters (Latin, Arabic, Cyrillic, Greek, Japanese, Chinese, Hebrew, Korean, etc.)

• Message library (up to 2000 messages) • User interface available in 29 languages • Large WYSIWYG backlit display • Creation of logos directly onto the user interface • Compact Flash and SD cards capable • USB port • Jet Speed Control for optimum print quality • Automatic font selection; print speed and printhead to substrate distance dependent • Range of inks: fast-dry inks and inks for applications requiring printhead motion • Sealed 0.8-liter cartridges with foolproofing system • Quick connection of the user interface panel for accessories (photocell, encoder, alarm) • RS-232/422 connectivity, parallel interface and I/O slot for remote access • Ethernet connectivity

• Weight: 40 kg • 3-meter flexible umbilical • Stainless steel cabinet • Dust/humidity protection rating: IP54 • No plant air required • Operating temperature range: 0° to 50° C • Humidity: 10% to 90% non-condensing • Electrical power supply: 100-120 V or 200-240 V with automatic switching; frequency 50/60 Hz; power 200 VA

• IP65 (requires plant air) • Printhead pressurization kit • Reinforced 5 or 8-meter umbilicals for applications requiring printhead motion • 90° bent umbilical • Printhead with umbilical lateral output  • Compatible with CoLOS Create Professional and CoLOS Enterprise • Logo creation with CoLOS Graphics

• Printhead stand (aluminum or stainless steel) • Various printhead brackets • Stainless steel printhead cover • Photocell • Encoder • Alarm beacon (24 V)
